齿数 |
节径
|
外径
|
规格
|
L |
10 |
6.47 |
5.96 |
10MXL100 |
100 |
11 |
7.11 |
6.61 |
11MXL100 |
12 |
7.76 |
7.25 |
12MXL100 |
13 |
8.41 |
7.90 |
13MXL100 |
14 |
9.06 |
8.55 |
14MXL100 |
15 |
9.70 |
9.19 |
15MXL100 |
16 |
10.35 |
9.84 |
16MXL100 |
17 |
11.00 |
10.49 |
17MXL100 |
18 |
11.64 |
11.14 |
18MXL100 |
19 |
12.29 |
11.78 |
19MXL100 |
20 |
12.94 |
12.43 |
20MXL100 |
21 |
13.58 |
13.08 |
21MXL100 |
22 |
14.23 |
13.72 |
22MXL100 |
23 |
14.88 |
14.37 |
23MXL100 |
24 |
15.52 |
15.02 |
24MXL100 |
25 |
16.17 |
15.66 |
25MXL100 |
26 |
16.82 |
16.31 |
26MXL100 |
27 |
17.46 |
16.96 |
27MXL100 |
28 |
18.11 |
17.60 |
28MXL100 |
30 |
19.40 |
18.90 |
30MXL100 |
32 |
20.70 |
20.19 |
32MXL100 |
36 |
23.29 |
22.78 |
36MXL100 |
40 |
25.87 |
25.36 |
40MXL100 |
44 |
28.46 |
27.95 |
44MXL100 |
48 |
31.05 |
30.54 |
48MXL100 |
50 |
32.34 |
31.83 |
50MXL100 |
60 |
38.81 |
38.30 |
60MXL100 |
70 |
45.28 |
44.77 |
70MXL100 |
72 |
46.57 |
46.06 |
72MXL100 |
80 |
51.74 |
51.24 |
80MXL100 |
84 |
54.33 |
53.82 |
84MXL100 |
96 |
62.09 |
61.59 |
96MXL100 |
100 |
64.68 |
64.17 |
100MXL100 |
120 |
77.62 |
77.11 |
120MXL100 |
规格 |
齿数 |
形状 |
节径 |
外径 |
W |
L |
K |
X |
轮彀直径 |
内孔 |
档边外径 |
档边内径 |
档边型号 |
20MXL |
20 |
C/A |
12.94 |
12.43 |
11 |
16 |
7 |
- |
9 |
6 |
18 |
11 |
F-101811 |
21MXL |
21 |
C/A |
13.58 |
13.08 |
11 |
16 |
7 |
- |
9 |
6 |
18 |
11 |
F-101811 |
22MXL |
22 |
C/A |
14.23 |
13.72 |
11 |
16 |
7 |
- |
9 |
6 |
18 |
11 |
F-101811 |
23MXL |
23 |
C/A |
14.88 |
14.37 |
11 |
16 |
7 |
- |
10 |
6 |
20 |
12 |
F-102012 |
24MXL |
24 |
C/A |
15.52 |
15.02 |
11 |
16 |
7 |
- |
10 |
6 |
20 |
12 |
F-102012 |
25MXL |
25 |
C/A |
16.17 |
15.66 |
11 |
16 |
7 |
- |
10 |
6 |
23 |
12 |
F-102312 |
26MXL |
26 |
C/A |
16.82 |
16.31 |
11 |
16 |
7 |
- |
10 |
6 |
23 |
12 |
F-102312 |
27MXL |
27 |
C/A |
17.46 |
16.96 |
11 |
16 |
7 |
- |
11 |
7 |
23 |
13 |
F-102313 |
28MXL |
28 |
C/A |
18.11 |
17.60 |
11 |
16 |
7 |
- |
11 |
7 |
23 |
13 |
F-102313 |
30MXL |
30 |
A/B |
19.40 |
18.90 |
11 |
16 |
7 |
- |
11 |
7 |
23 |
13 |
F-102313 |
32MXL |
32 |
A/B |
20.70 |
20.19 |
11 |
16 |
7 |
- |
13 |
8 |
26 |
16 |
F-102516 |
36MXL |
36 |
A/B |
23.29 |
22.78 |
11 |
16 |
7 |
- |
15 |
10 |
28 |
18 |
F-102818 |
40MXL |
40 |
A/B |
25.87 |
25.36 |
11 |
18 |
7 |
- |
17 |
10 |
31 |
20 |
F-103120 |
48MXL |
48 |
A/B |
31.05 |
30.54 |
11 |
18 |
7 |
- |
18 |
10 |
35 |
22 |
F-103522 |
60MXL |
60 |
A/B |
38.81 |
38.30 |
11 |
18 |
7 |
- |
28 |
20 |
44 |
32 |
F-104432 |
72MXL |
72 |
A/B |
46.57 |
46.06 |
11 |
18 |
7 |
- |
30 |
20 |
51 |
36 |
F-105136 |
84MXL |
84 |
A/B |
54.33 |
53.82 |
11 |
18 |
7 |
- |
35 |
23 |
61 |
41 |
F-106141 |
96MXL |
96 |
A/B |
62.09 |
61.59 |
11 |
18 |
7 |
- |
42 |
28 |
69 |
50 |
F-106950 |
120MXL |
120 |
A/B |
77.62 |
77.11 |
11 |
18 |
7 |
- |
56 |
37 |
86 |
66 |
F-108666 |
